Channels: 96
Groups: A or B
Oscillator Type: PLL Synthesizer
Frequency Range: 514 MHz – 596 MHz
Reference Deviation: +/- 5 kHz (-60dBV, 1kHz input)
Signal to Noise Ratio: 70 dB or more
Spur Suppression: -60 dB
Voice Delay: 12 ms
Antenna: 1/4λ wire antenna
Audio input connector: TX9:3.5mm mini jack
HU9: noneTX-XLR9: XLR-3-11C type (female)
Reference audio input level: -60dBV (MIC input, 0dB attenuation)
Distortion: 0.5% or less
Weight: TX9: Approx. 211.4g (excluding batteries)
HU9: Approx. 338.2g (excluding batteries)

TX-XLR9: Approx. 138g (Excluding batteries)

Battery: Two AA size batteries
Dimensions: TX9: 170.9 x 63.5 x 30.0 mm
HU9: 254.0 x 52.0 x 52.0 mm
TX-XLR9: 105.5 x 43 x 34.7 mm
Operating temperature: 0℃ to 50℃
Storage temperature: -20℃ to +55℃
Receiver
Channels: 96
Groups: A or B
Oscillator Type: PLL Synthesizer
Audio output connector: 3.5mm mini jack
Antenna: 1/4λ wire antenna
Audio output level: -60dBV
Headphone output level: 30mW (16Ω)
Receiver frequencies: 514 MHz – 596 MHz
Signal to Noise Ratio: 70 dB or more
Voice Delay: 12 ms
Reference Deviation: +/- 5 kHz (-60dBV, 1kHz input)
Frequency response: 40Hz to 18kHz (+/-3dB)
Distortion: 0.5% or less
Spur Suppression: -60 dB
Weight: 218.7g (Excluding batteries)
Battery: Two AA size batteries
Dimensions: 170.9 x 63.5 x 30.0 mm
Operating temperature: 0℃ to 50℃
Storage temperature: -20℃ to +55℃
